DLCV-150 Series

DALI-2&PUSH Dimming LED Power Supply

 - DALI-2& PUSH ( 2 in 1) Dimming
- Dimming range: 1-100%
- DALI-2 Certified
- Safety standard: EN61347-1,EN61347-2-13,
- UL8750+1310    CAN/CSA C22.2 No.250.13
- FCC CFR Title 47 Part 15
- EMI standard:EN55015
- EMS standard: EN61547
- ERP: EU2019/2020
- Protection:Short Circuit/Overload/Over Voltage/Over Temperature
- 100% full load burn in test
- Auto restart after remove of fault conditions
- RoHS Compliance

Constant Voltage

Model Power

(max.)

Input

Voltage

Output Voltage Output Current(max.) Voltage Tolerance Efficiency Dimension(LxWxH) Dimming
DLCV-150-12 150W 220-240V AC 12V 12.5A ±5% 92% 308×45.5×30.5mm Dali&Push
DLCV-150-24 150W 220-240V AC 24V 6.25A ±5% 92% 308×45.5×30.5mm Dali&Push
DLCV-150-36 150W 220-240V AC 36V 4.16A ±5% 92% 308×45.5×30.5mm Dali&Push
DLCV-150-48 150W 220-240V AC 48V 3.125A ±5% 92% 308×45.5×30.5mm Dali&Push
DLCV-150-12-V 150W 220-240V AC 12V 12.5A ±5% 92% 308×45.5×30.5mm 0-10V
DLCV-150-24-V 150W 220-240V AC 24V 6.25A ±5% 92% 308×45.5×30.5mm 0-10V
DLCV-150-36-V 150W 220-240V AC 36V 4.16A ±5% 92% 308×45.5×30.5mm 0-10V
DLCV-150-48-V 150W 220-240V AC 48V 3.125A ±5% 92% 308×45.5×30.5mm 0-10V
