- DALI-2& PUSH ( 2 in 1) Dimming
- Dimming range: 1-100%
- DALI-2 Certified
- Safety standard: EN61347-1,EN61347-2-13,
- UL8750+1310 CAN/CSA C22.2 No.250.13
- FCC CFR Title 47 Part 15
- EMI standard:EN55015
- EMS standard: EN61547
- ERP: EU2019/2020
- Protection:Short Circuit/Overload/Over Voltage/Over Temperature
- 100% full load burn in test
- Auto restart after remove of fault conditions
- RoHS Compliance
Constant Voltage
| Model | Power
(max.) |
Input
Voltage |
Output Voltage | Output Current(max.) | Voltage Tolerance | Efficiency | Dimension(LxWxH) | Dimming |
| DLCV-100-12 | 100W | 220-240V AC | 12V | 8.33A | ±5% | 90% | 308×45.5×30.5mm | Dali&Push |
| DLCV-100-24 | 100W | 220-240V AC | 24V | 4.16A | ±5% | 90% | 308×45.5×30.5mm | Dali&Push |
| DLCV-100-36 | 100W | 220-240V AC | 36V | 2.78A | ±5% | 90% | 308×45.5×30.5mm | Dali&Push |
| DLCV-100-48 | 100W | 220-240V AC | 48V | 2.08A | ±5% | 90% | 308×45.5×30.5mm | Dali&Push |
| DLCV-100-12-V | 100W | 220-240V AC | 12V | 8.33A | ±5% | 90% | 308×45.5×30.5mm | 0-10V |
| DLCV-100-24-V | 100W | 220-240V AC | 24V | 4.16A | ±5% | 90% | 308×45.5×30.5mm | 0-10V |
| DLCV-100-36-V | 100W | 220-240V AC | 36V | 2.78A | ±5% | 90% | 308×45.5×30.5mm | 0-10V |
| DLCV-100-48-V | 100W | 220-240V AC | 48V | 2.08A | ±5% | 90% | 308×45.5×30.5mm | 0-10V |
